Technical data |
Specification |
CPU |
Intel JASPER LAKE N5105 qual-core 2.9GHz |
OS |
windows 10 Home 64bit Not activated |
LCD |
12.2 inch 1920x1080 280nits PCAP touch |
RAM |
8G/16G DDR4L |
Flash |
128GB/256GB/512GB SSD |
WiFi |
WIFI 802.11(a/b/g/n/ac) 2.4G+5.8G dual-band |
Camera |
Front2.0MP,Rear8.0MP |
BT |
BT4.2 |
Battery |
7.4V/860mAh +6300mAh/7.4V |
Speaker |
Built-in 8O/0.8W Speaker x 1 |
Sensor |
G-Sensor |
4G |
LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8 |
GPS |
U-BLOX M8Q support GPS, Glonass and BDS |
USB |
USB 3.0 x1, USB Type-C x1 |
TF Card Slot |
Support TFx1 max:128G |
Earphone Jack |
?3.5mm standard headphone port |
Ethernet |
x1 (10/100Mbps) RJ45, coule be replaced by serial port/USB port/1D scanner/2D scanner |
HDMI connector |
HDMI 1.4a mini x1 |
Optional |
OS Lisence |
Windows 10 Home(8G DDR4 +128GB) Windows 10 Pro OS (8G DDR4 +128GB) Windows 10 IOT Enterprise |
SSD Upgrade |
128GB update to 256GB 128GB update to 512GB |
NFC |
support 13.56mHz NFC |
USB2.0 |
USB type-A |
DB9 |
RS232 serial port |
1D barcode scanner |
MOTO module |
2D barcode scanner |
Honeywell module |
Accessory |
Additional Adaptor |
100~240V input; 19V3.42A/65W ouput CE |
Additional Battery |
6300mAH/7.4V |
Stylus |
Passive Stylus |
Car Charger |
19V/3A |
Docking |
DC10U |
