| Technical data |
| General Data |
| Power supply | 19,2..30 Vdc / 50-60 Hz |
| Power consumption | 500 mW |
| Isolation | 1.500 Vac (3 way) |
| Transducer Power Supply | --- |
| Accuracy | 0,1% |
| Response time | < 50 ms (without filter)
< 200 ms (with repeat filter 50 Hz) |
| Status Indicators | Setting error, connection malfunction, internal malfunction |
| Setting | Dip-switches |
| Mounting | 35 mm DIN rail guide |
| Protection Degree | IP20 |
| Operating |
| Temperature | -20..+65 °C |
| Dimension | (W x H x ) 6,2 x 93 x 102,5 mm |
| Input |
| Channel Numbers | 1 |
| RTD | Pt100
Measure 2, 3, 4 wires
Range: -150..650 °C
Resolution 14 bit |
| Output |
| Channel Numbers | 1 |
| Voltage | 4 scales: 0..10, 10..0, 0..5, 1..5 V
Min load resistance: 2.000 O |
| Current | 2 scales: 0/4..20 mA (active/passive)
Max load resistance: 500 O |
| Standard |
| Approval | CE |
| Norms | EN 50081-2; EN 55011; EN 50082-2; EN 61000-2-2/4; EN 50140/141; EN 61010-1 |
